AFBR-57R5APZ
AFBR-57R5APZ
- Part Number
- AFBR-57R5APZ
- Manufacturer
- AVAGO
- Condition
- Any
- Category
- Optical & Access
In stock
The Avago AFBR-57R5APZ is an SFP optical transceiver with a single LC duplex port. It operates at 850 nm and supports data rates up to 4.25 Gbps, drawing 1.0 W from a 3.3 V ±10% supply. Its compact housing measures 5.53 × 1.35 × 0.85 cm and weighs 0.02 kg. The module is rated for operating temperatures from -10 °C to 85 °C.
Specifications
| Weight | 0.0200 kg / 0.04 lbs |
|---|---|
| Volumetric Weight (L×W×H÷5000) | 0.001 kg / 0.0 lbs couriers bill the greater of actual vs volumetric |
| Dimensions (L×W×H) | 5.5300 × 1.3500 × 0.8500 cm / 2.2 × 0.5 × 0.3 in |
| Part Type | Optical Transceiver |
| Data Rate | 4.25 Gbps |
| Form Factor | SFP |
| Wavelength Nm | 850 |
| Connector | LC duplex |
| Ports | 1 port |
| Power W | 1.0 |
| Voltage V | 3.3V ± 10% |
| Compatible Systems | Gigabit Ethernet, Fibre Channel, and other SFP-compliant systems |
| Temp Min C | -10.0 |
| Temp Max C | 85.0 |
| Dim Notes | Dimensions from the module specifications. |
| Spec Notes | Specifications based on product data. |
| Dim Confidence | datasheet |
| Brand | AVAGO |
| Part Number | AFBR-57R5APZ |
| Condition | Any |
| Availability | In stock — bulk pricing on request |
About This Equipment
Designed for use in Gigabit Ethernet, Fibre Channel, and other SFP-compliant systems, this transceiver provides a pluggable optical interface for carrier-grade and data-centre network links. It is suited to deployments where a reliable 850 nm SFP connection is required. Condition and availability are confirmed via quote.
